Firebolt Models Parts Catalog
2004
EXHAUST SYSTEM - AX12
| Index No. | Part No. | Description | Models | Obselete |
|---|---|---|---|---|
| 1 | 65184-02 | FLANGE, exhaust pipe (2) | XB9R | |
| 2 | 65324-83B | GASKET, exhaust port (2) | XB9R | |
| 3 | 65325-83A | RETAINING RING, exhaust (2) | XB9R | |
| 4 | AA0624.1CZB | SCREW (2) | XB9R | |
| 5 | BA0613.2Z | WASHER, flat (2) | XB9R | |
| 6 | DA0400.1FZB | NUT (3) | XB9R | |
| 7 | DA0500.12FZ | LOCKNUT (4) | XB9R | |
| 8 | S0101.02A8A | HEADER | XB9R | |
| 9 | S0111.02A8 | MUFFLER | XB9R | |
| 10 | S0127.8A | CLAMP, 2 in. torca | XB9R | |
| 11 | S0133.02A8A | MUFFLER BRACKET, rear | XB9R | |
| 12 | S0135.02A8A | MUFFLER MOUNT, front | XB9R | |
| 13 | S0136.02A8 | BUSHING, front muffler mount (2) | XB9R | |
| 14 | S1002.02A8 | HARDWARE KIT, w/ screw & nut | XB9R | |
| 15 | S1116.02A8 | MUFFLER STRAP, front, w/ nut | XB9R | |
| 16 | S1123.02A8 | MUFFLER STRAP, rear, w/ nut (2) | XB9R | |
| 17 | S0144.02A8 | MUFFLER, w/ heat shield (Japan) | XB9R | Nov 2014 |
